China Fire Monitor Quadruped Robot: Innovative Suppliers for Advanced Firefighting Solutions from Our Factory
Key Features
Dual-Mode Water Cannon, Precision Fire Suppression
Equipped with straight stream and wide spray modes, with a maximum range of up to 60 meters. Adjustable flow rate enables both concentrated fire suppression and wide-area coverage, adapting flexibly to different fire scenarios.
Built for Extreme Environments
Capable of wading through water up to 1 meter deep, climbing steps up to 30cm, and traversing slopes up to 40°. Integrated water curtain cooling system ensures stable operation under high-temperature conditions.
Remote Control with Real-Time Video Transmission
Supports long-distance remote operation and HD real-time video transmission with ultra-low latency, enabling command centers to monitor the fire scene in real time and accurately assess fire dynamics.
Application Scenarios
Confined Space Fire Suppression
In confined spaces such as energy storage containers, metro systems/tunnels, and underground parking garages, it can replace firefighters in entering high-temperature, smoke-filled environments to rapidly suppress the fire and create a safe passage for subsequent rescue operations.
Petrochemical Tank Area Fire
At hazardous chemical incident sites involving flammable, explosive, and toxic substances, the robot can approach the fire source to carry out precise firefighting operations. Equipped with a foam cannon, it can efficiently extinguish oil-based fires.
Forest Firefighting
Capable of traversing rugged mountain trails and rocky slopes, it can efficiently carry out fire suppression on the front lines of wildfires. After the operation, it can remain on standby to continuously monitor and provide early warning of potential reignition.
Urban Complex Fires
Capable of climbing stairs to enter shopping malls, office buildings, and other structures, it can quickly locate fire sources in smoke-filled environments and suppress them efficiently, creating a safe evacuation path for people.
Product Parameters
| Mechanical Parameters | Dimensions (Standing) | 1150mm × 454mm × 905mm |
| Weight | 70kg | |
| Operating Temperature | -20℃~50℃ | |
| Operating Humidity | 20%RH~80%RH | |
| Electrical Parameters | Operating Time | ≥3h |
| Battery Capacity | 22.4Ah | |
| Auto Charging | Supported | |
| Protection Rating | IP65 | |
| Performance Parameters | Max Speed | 2.9m/s |
| Terrain Adaptability | Suitable for gravel, rubble, ruins, stairs, tunnels, uneven terrain, mud, etc. | |
| Max Slope Angle | ≥30° | |
| Stair Climbing Height | ≥16cm | |
| Interchangeable Module | Supported (Fire Extinguisher Module) | |
| Water Cannon Firefighting (Optional) | Spray Modes | Straight stream and spray (fog) modes |
| Effective Range | >40m | |
| Max Spray Angle | ≥120° | |
| Horizontal Rotation | ±20° | |
| Pitch Angle | 10° ~ +50° | |
| Water Cannon Performance | Straight stream/spray modes; remote wireless control; flow rate ≥20 L/s | |
| Spray Connection | Quick-connect interface; supports single DN80 line; equipped with remote-controlled self-release function | |
| Self-Spray Cooling | Supported | |
| Fire Extinguishing Agent Fire (Optional) | Fire Extinguishing Type | Categories A, B, E, F |
| Agent Capacity | ≥9L | |
| Jet Distance | ≥3m | |
| Fire Suppression Range | The maximum effective range in a standing posture is approximately 10.6 square meters (a sector with a radius of 4.5 meters and a central angle of 60°) | |
| Continuous Extinguishing Time | ≥30s | |
| Others | Fire Situation Investigation | 10x continuous optical zoom, supports thermal imaging, laser ranging, and rapid multi-target recognition and tracking functions. Equipped with visual intelligence to identify fire sources, enabling real-time guidance and precise firefighting. |
| Emergency Stop | Equipped with both hardware and software emergency stop | |
| Controller Dimensions | ≤380mm (L) × 240mm (W) × 48mm (H) (excluding joystick height) | |
| Display Size | 10.1 inches | |
| Display Resolution | 1920 × 1200, touchscreen supported | |
| Communication Module | 4G / Wi-Fi / radio | |
| Communication Range | ≥500m | |
| Sensor Configuration | LiDAR, RGB camera |
